A double-wall corrugated box has three flat facings and two corrugated mediums (NMFC Item 222-6). Its common grade, 275# burst or 48 ECT, may carry 100 lb of box and contents at up to 95 in of outside length + width + depth under rail Rule 41; the six double-wall grades run from 200# or 42 ECT (80 lb, 85 in) to 600# or 82 ECT (180 lb, 120 in). At 275#, B/C board is .264 in thick and A/C .344 in (Walmart’s caliper chart). Uline’s 24 x 24 x 24 in double-wall box measures 24 3/4 x 24 3/4 x 25 in outside. FedEx: use double-wall boxes for heavier items.
| Box and contents, max, 275# or 48 ECT | Outside length + width + depth, max | B/C board, 275# |
|---|---|---|
| 100lb45.4 kg | 95in2,413 mm | .264in.677 cm |
Sources: Rule 41, Walmart caliper chart. Checked October 2026.
Uline’s 24 x 24 x 24 in double-wall box, measured outside, and the 275# or 48 ECT limits are filled in. Enter your gross weight; each check uses the numbers in the tables on this page.
Sizes in millimetres, weights in kilograms, the box measured outside (1 in = 25.4 mm, 1 lb = 0.4536 kg). Boxes stand upright, in straight columns.
629 + 629 + 635 = 1893 mm, within 2413 mm, and 35 kg is within the 45.4 kg limit of this grade.
Filled in: Rule 41’s 275# or 48 ECT row, 100 lb (45.4 kg) and 95 in (2,413 mm), and Uline’s 24 × 24 × 24 in double-wall box, 24 3/4 × 24 3/4 × 25 in outside.
Boxes of 629 × 629 mm fit 1 per layer on the 1219 × 1016 mm deck without overhang, and 635 mm boxes go 2 high under 1778 mm with the 141 mm pallet: 2 a pallet, enough for 2.
Side by side two of these boxes take 1,258 mm, more than the 1,219 mm pallet, so a layer holds one. Stack in columns: FBA’s study lost 49 – 54% of compression strength interlocked.
Loose and upright, the boxes go 27 per layer and 3 high in 2393 mm: 81, enough for your 80, and 2800 kg is within the 28380 kg payload.
A layer in Triton’s 20 ft takes 9 along by 3 across of the 629 mm boxes, 3 layers high, by our calculation.
Exporting heavy goods in double-wall cartons? Photograph one packed, mark its outside size, board and weight in SizeMarker and send it with the packing list.
Mark a photoBurst test (psi) or edge crush test (ECT, lb per inch); size is the outside length, width and depth added. Metric in grey is our conversion.
| Grade | Box and contents, max | L + W + D, max |
|---|---|---|
| 200# burst or 42 ECT | 80 lb36.3 kg | 85 in2,159 mm |
| 275# burst or 48 ECTThe common grade; Rule 41, Section 3 | 100 lb45.4 kg | 95 in2,413 mm |
| 350# burst or 51 ECT | 120 lb54.4 kg | 105 in2,667 mm |
| 400# burst or 61 ECT | 140 lb63.5 kg | 110 in2,794 mm |
| 500# burst or 71 ECT | 160 lb72.6 kg | 115 in2,921 mm |
| 600# burst or 82 ECT | 180 lb81.6 kg | 120 in3,048 mm |
Sources: Rule 41
| Item | What the source says |
|---|---|
| BuildNMFC Item 222-6 | Three flat facings and two intermediate corrugated mediums |
| Build, in the FBA’s wordsFibre Box Association | Three sheets of linerboard with two mediums in between |
| B/C board, 200# to 600#Walmart caliper chart | .258 in to .308 in; 275#: .264 in (.677 cm) |
| A/C board, 200# to 600#Walmart caliper chart | .338 in to .388 in; 275#: .344 in (.882 cm) |
| For single wall, C flute 200#Walmart caliper chart | .159 in |
| When to use itFedEx | Use double-wall boxes for heavier items |
| Against single wallUline | Double the protection of a 200 lb. test box; use when extra stacking strength is needed |
| Glass over 65 lb grossNMFC Item 222-2 | Inner containers up to one gallon may ship in doublewall testing not less than 275 pounds or 48 ECT; gross weight up to 100 pounds, inside dimensions up to 100 inches |
| Parcel guidanceUline, citing UPS | 200#: 60 lbs; 275#: 80 lbs; 350#: 100 lbs; 500#: 140 lbs |
Sources: NMFC Item 222 · Fibre Box Association · Walmart caliper chart · FedEx (How to Pack) · Uline (S-15062) · Uline (S-4740)
Inside length × width × depth unless marked outside. All from distributors’ listings.
| Box | Size | Grade; weight or rating |
|---|---|---|
| Uline S-4740 | 24 x 24 x 24 inOutside 24 3/4 x 24 3/4 x 25 in | 275 lb. test double wall; 6.20 lbs; UPS 80 lbs |
| Uline S-15062 | 48 x 24 x 12 inOutside 48 3/4 x 24 3/4 x 13 in | 275 lb. test double wall; 7 lbs; UPS 80 lbs |
| Global Industrial WBB39762 | 18 x 18 x 18 in | 275# DW/ECT-48 |
| Baytec 8HD242412DW | 24 x 24 x 12 in | 275# D.W./ECT-48; 48 lb a bundle of 10 |
| Lavex 442BOX302412HDDW | 30 x 24 x 12 in | ECT 48; rated to hold up to 80 lb |
| Uline S-4740 outside, in mmOur conversion | 629 × 629 × 635 mm | — |
Sources: Uline (S-4740) · Uline (S-15062) · Global Industrial (double wall) · Baytec · Lavex (double wall)
| Rule or figure | What it says |
|---|---|
| Column vs interlockFBA study, Table 12 | Columnar aligned: 12 – 20% less compression strength; interlocked: 49 – 54% |
| Palletized freightFedEx Freight | Column-stack loads |
| InterlockingYRC Freight | Can reduce top-to-bottom compression strength up to 50 percent |
| CHEP B4840A palletCHEP | 1219 × 1016 × 141 mm48 × 40 in |
| Two S-4740 side by sideOur calculation | 1,258 mm, more than the 1,219 mm pallet: one a layer |
| Skid heightFedEx Express Freight | Over 70 in needs prior approval1,778 mm, our conversion |
| 20 ft insideTriton | 5,898 × 2,352 × 2,393 mm; 28,380 kg payload |
| S-4740 in that 20 ft, looseOur calculation | 9 along by 3 across, 27 a layer; 3 layers: 81 |
Sources: FBA pallet pattern study · FedEx Freight · YRC Freight · CHEP (B4840A) · FedEx (How to Pack) · Triton (20ft)
A box of three flat facings and two corrugated mediums (NMFC Item 222-6). Rule 41 lists six double-wall grades, from 200# or 42 ECT to 600# or 82 ECT, and the 275# or 48 ECT grade is the common one.
Under rail Rule 41, 275# or 48 ECT allows 100 lb of box and contents with outside length + width + depth up to 95 in, and 600# or 82 ECT allows 180 lb and 120 in. For parcels Uline cites UPS at 80 lbs for 275# and 140 lbs for 500#.
At 275#, B/C board is .264 in (.677 cm) and A/C .344 in (.882 cm) in Walmart’s caliper chart, against .159 in for single-wall C flute at 200#.
For heavier items, says FedEx, and when extra stacking strength is needed, says Uline. Under NMFC Item 222-2, glass in inner containers up to one gallon, over 65 lb gross, may ship in double wall testing not less than 275 pounds or 48 ECT.
In columns: FedEx Freight says column-stack loads, and in the FBA study interlocked boxes lost 49 – 54% of their compression strength against 12 – 20% aligned. Measure outside: two of Uline’s 24 in boxes take 1,258 mm, more than a 1,219 mm pallet.
