A circular (tubular) bulk bag is woven as a tube on a circular loom and cut to length, so it has no vertical seams (Palmetto). Stock circular bags sit on a 35 × 35 in base, 30 to 64 in tall, rated 2200 to 3000 lbs: Halsted’s 35x35x40" bag takes 2200lbs at 5:1, and BAG Corp’s 35" x 35" x 46" holds 38 Cubic Feet and 2200 lbs. Without side seams it resists sifting and moisture, and BAG Corp sells it without a liner for fine and hygroscopic materials. Filled it rounds out: Taihua’s UN-tested 900x900x800mm bag measures φ1150x850mm filled, and Bulk-Pack gives 45-48 in. for the standard filled diameter, two across in a container. For a round bag, ISO 21898 counts the fill height against the base diameter.
| Base, stock US bags | Heights, Halsted and BAG Corp | SWL, stock bags |
|---|---|---|
| 35 × 35in889 × 889 mm | 30–64in762–1,626 mm | 2200–3000lbs998–1,361 kg |
Sources: Halsted (BB-40U5DS), BAG Corp (3530DSUN2T), BAG Corp (3552DSCN3T). Checked October 2026.
BAG Corp’s 35" x 35" x 46" tubular bag is entered at Bulk-Pack’s 45 in filled diameter, with Transoplast’s 1200 × 1200 mm pallet and Triton’s 20 ft. Enter your bulk density; each check uses the numbers in the tables on this page.
Sizes in millimetres, weights in kilograms, bulk density in kg per cubic metre (1 g/cm³ = 1,000 kg/m³). A filled bag is wider than its base, so enter the filled size; for a bag that rounds out, its filled diameter as both length and width.
1.08 m³ × 900 kg/m³ = 972 kg, 26 kg under the 998 kg safe working load.
Filled in: BAG Corp’s tubular 35" x 35" x 46" bag, 38 Cubic Feet (1.08 m³) and 2200 lbs (998 kg).
Filled, the bag takes 1143 × 1143 mm of the 1200 × 1200 mm pallet, leaving 57 mm and 57 mm of deck.
Bulk-Pack: the standard filled diameter is 45-48 in.; 45 in is 1,143 mm, on Transoplast’s 1200 × 1200 mm pallet. Taihua’s 900 mm bag measures φ1150 mm filled.
Bags of 1143 × 1143 mm go 10 per layer, 1 high: 10, enough for your 10, and 10 × 973.5 kg = 9735 kg is within the 28380 kg payload.
Two 1,143 mm bags side by side take 2,286 mm of the 2,352 mm width: two across, as Bulk-Pack says. One high; FIBCA: stack only bags designed to be stacked.
Shipping fine powders in circular bags? Photograph a filled bag, mark its diameter, height and spouts in SizeMarker and send it with the packing list.
Mark a photoBase × height as each maker prints it.
| Bag | Size | SWL; SF; fabric or volume |
|---|---|---|
| Halsted BB-35UOFOpen top; 4 x 10" cross corner loops | 35x35x35" | 2500lbs; 5:1; 180gsm uncoated |
| Halsted BB-40U5DS | 35x35x40" | 2200lbs; 5:1; 160gsm uncoated |
| Halsted BB-3964USSBottom spout 22" x 24" | 39x39x64" | 2500lbs; 5:1; 140gsm |
| BAG Corp 3546DXUN2T | 35" x 35" x 46" | 2200 lbs; 38 Cubic Feet; 8oz. uncoated |
| BAG Corp 3552DSCN3T | 35" x 35" x 52" | 3000 lbs; 43 Cubic Feet |
| BAG Corp 37x37x60 | 37" x 37" x 60" | 3000 lbs; 61 Cubic Feet |
| BAG Corp 3530DSUN2TLinerless | 35" x 35" x 30" | 2200 lbs; 24 Cubic Feet |
| BAG Corp 3550SSCN2T-UNUN, packing groups II and III | 35" x 35" x 50" | Up to 2205 lbs; 42 cubic feet |
Sources: Halsted (BB-35UOF) · Halsted (BB-40U5DS) · Halsted (BB-3964USS) · BAG Corp (3546DXUN2T) · BAG Corp (3552DSCN3T) · BAG Corp (37x37x60) · BAG Corp (3530DSUN2T) · BAG Corp (3550SSCN2T-UN)
Taihua’s test report for a dangerous-goods bag, January 2025.
| Item | Figure |
|---|---|
| Type and size | Tubular, 900x900x800mm |
| Filled size | φ1150x850mm |
| Fabric | 190g/㎡, white, double layer |
| Empty weight | 3.14kg |
| Maximum permissible gross mass | 2000kg |
| UN markStacking test load 10800 kg; max gross 2000 kg | 13H2/Y/0724/CN/C231803/10800/2000 |
| Code 13H2RID 6.5.5.2.1 | Woven plastics, coated |
| Stacking test | Passed |
Sources: Jiangsu Taihua (UN test) · RID 2025
| Item | What the source says |
|---|---|
| FabricPalmetto glossary | Woven on a circular loom, cut to length for the bag height, so there are no vertical seams on the sides |
| No side seamsBAG Corp | Improved sift and moisture resistance |
| LinerBAG Corp; United Bags | A linerless option for fine and hygroscopic materials; fine and powdery materials often do not require an inner liner |
| Square baseKanplas | Eight reinforcing sections are woven in on the loom so it can be sewn onto a square base with four corners |
| LoopsKanplas; Halsted | Cross-corner handles |
| WidthsKanplas | 90cm to 100cm; SWL 500kg to 2500kg |
| Fill heightISO 21898:2024, 4.3 | For a circular cross-section the shortest horizontal dimension is normally the base diameter |
| Filled height to widthRID 6.5.5.2.9 | Not more than 2:1 |
Sources: Palmetto (glossary) · BAG Corp (3546DXUN2T) · BAG Corp (3530DSUN2T) · United Bags (circular) · Kanplas (circular) · Halsted (BB-35UOF) · ISO 21898:2024 · RID 2025
| Rule or figure | What it says |
|---|---|
| OverhangFIBCA | Use a pallet of appropriate size so the FIBC does not overhang the side |
| Standard filled diameterBulk-Pack | 45-48 in., designed to fit two across in a truck or a shipping container |
| 45 in, in mmOur conversion | 1,143 mm |
| 1200 × 1200 mm palletTransoplast | 1200 × 1200 mm |
| A φ1150 or 1,143 mm bag on itOur calculation | 25 to 29 mm of deck each side |
| 20 ft insideTriton | 5,898 × 2,352 × 2,393 mm; 28,380 kg payload |
| 1,143 mm bags in that 20 ftOur calculation | 5 along, 2 across: 10 a layer; two across take 2,286 mm |
| BAG Corp 3546DXUN2T in metricOur conversion | 38 Cubic Feet = 1.08 m³; 2200 lbs = 998 kg; 46" = 1,168 mm; 3000 lbs = 1,361 kg |
| Stock heights in mmOur conversion | 30 in = 762 mm; 64 in = 1,626 mm; 35 in = 889 mm |
Sources: FIBCA · Bulk-Pack · Transoplast · Triton (20ft)
Stock circular bags in the US are 35 × 35 in at the base, like U-panel bags, and 30 to 64 in tall: BAG Corp sells 35" x 35" x 30" to 35" x 35" x 52", Halsted 35x35x35" to 39x39x64". Kanplas makes them 90cm to 100cm wide.
A bag made from fabric woven on a circular loom and cut to length for the bag height, so it has no vertical seams on its sides (Palmetto). Eight reinforcing sections woven in on the loom let it be sewn onto a square base (Kanplas).
Often not for fine powders: without side seams it has improved sift and moisture resistance, and BAG Corp sells a linerless version for fine and hygroscopic materials. United Bags says fine and powdery materials often do not require an inner liner.
Bigger than its base: Taihua’s 900x900x800mm bag measures φ1150x850mm filled, and Bulk-Pack gives 45-48 in. for the standard filled diameter, two across in a truck or a container. FIBCA says it must not overhang the pallet.
At a 1,143 mm filled diameter, 5 along and 2 across: 10 a layer in Triton’s 20 ft, by our calculation; two across take 2,286 mm of the 2,352 mm width. Stack only bags designed to be stacked (FIBCA).
Buyers of fine powders, cement and fertilizer ask whether the bag is circular woven or sewn, whether it needs a liner, its filled diameter and how many go two across in a container. Mark the real bag, its diameter, loops and spouts on your own product photo in SizeMarker, as in the picture at the top, and send one product card for WhatsApp or WeChat.
