Appliance cutout dimensions are the one set of numbers your buyer cannot guess, and the one most export cabinet catalogs leave out. The buyer measures the cabinet you shipped, orders a dishwasher, and finds the opening is a few millimetres too narrow. Somebody now pays for the rework — and on an export order, that somebody is usually you.
This is not a design problem. It is a documentation problem. Below are the eight questions that decide whether a built-in appliance fits the cabinet you sold, answered in the order a sourcing manager actually asks them.
What are appliance cutout dimensions?
Appliance cutout dimensions are the width, height and depth of the empty opening a built-in appliance needs — measured between the inside faces of the surrounding cabinetry or the hole in the worktop — not the outside dimensions of the appliance itself.
That distinction is the whole article. GE Appliances spells it out in its own support documentation for wall ovens, noting that "the oven cut-out plus the overlap will be more than the overall oven dimensions" (GE Appliances, wall oven cut-out and overlap). Three different numbers describe one appliance, and they are not interchangeable.
Why isn't a "24-inch dishwasher" 24 inches wide?
Because the number in the model name is the opening, not the object.
This is the single most expensive misunderstanding in kitchen export, and the trade says so plainly. In a long-running cabinetmakers' knowledge base on the subject, a practitioner puts it this way: "The designation (24″, 30″ etc.) is not the actual appliance width in most cases, but the recommended opening dimension." The same thread carries the field convention for a slide-in range — "30 1/4″ is standard for a 30″ stove… Any less makes it hard for the installer and the customer" — and a blunt account of what happens when the cabinets go out before anyone checks: "we delivered and installed cabs. When appliances showed up, they didn't fit… we charged for it" (WOODWEB, Appliance Cutouts).
The appliance is built a little smaller than its nominal size so it can slide into a nominal opening. Publish the nominal size as if it were a measurement and you have published a number that is wrong by design. It is the same trap as nominal vs actual dimensions in sheet goods and lumber, transplanted into the kitchen.
Is there a standard that fixes appliance cutout dimensions?
There are standards for coordinating sizes, and they are not the same thing as a cutout table you can copy.
| Standard | Title | Status | What it actually covers |
|---|---|---|---|
| EN 1116:2018 | Furniture — Kitchen furniture — Coordinating sizes for kitchen furniture and kitchen appliances | Current (approved by CEN 27 Nov 2017) | Coordinating sizes for kitchen units, worktops, fronts, panelling, plus appliances and installation elements such as sinks; excludes commercial and hotel kitchens |
| ISO 3055:2021 | Kitchen equipment — Coordinating sizes | Current, published 31 Dec 2021; supersedes ISO 3055:1985, now withdrawn | Height, width and depth of kitchen units and worktops, and the space for integrating appliances such as sinks, ovens and refrigerators |
| ANSI/KCMA A161.1 | Performance & Construction Standard for Kitchen and Vanity Cabinets | Current, voluntary certification | Structural and finish performance — shelf loading, drawer cycling, door operation, finish durability. Not a dimensional standard |
Read that last row twice, because it catches people. A KCMA-certified cabinet has passed load and durability testing (KCMA, Quality Cabinet Certification). It says nothing about whether a 30-inch range will fit the opening.
And the two coordinating-size standards, real as they are, sit behind a paywall — their numeric module tables are not public (NEN, NEN-EN 1116:2018; BSI, BS ISO 3055:2021). Practically, the market runs on manufacturer conventions clustered around a 60 cm module in Europe and inch-based openings in North America, and the binding number for any specific unit is the one in that model's installation instructions. The honest way to write your catalog is: state the opening you built, and tell the buyer to check it against the appliance's own template.
Cutout, overlap, overall — which one goes in the catalog?
All three, labelled. They answer different questions.
| Number | What it describes | Who needs it |
|---|---|---|
| Cutout / niche | The empty opening: width × height × depth between the inside faces | The cabinet maker and the installer — this is the number that decides fit |
| Overlap / trim | How far the appliance's frame or trim laps over the cabinet face | The designer checking the finished sightline |
| Overall / product | The appliance's own outside dimensions | Logistics, door clearance, lift planning |
If your catalog shows only the third one — and most do — you have given the buyer the least useful of the three.
How much clearance does the appliance need around the opening?
More than the opening. Air gaps and door swing are separate from cutout, and they are where a technically correct cabinet still fails at installation.
GE publishes minimum air clearance for refrigerators as 1/8 inch up to 1 inch at each side and 1 inch above the case (GE Appliances, minimum air clearance requirements). On the rear clearance, GE's own two support pages are not identical — one gives "1″ to 2″ in the back", the other states a flat "2 inches in the back" (GE Appliances, general list of minimum air clearance requirements). That inconsistency inside a single manufacturer's documentation is exactly why you cite the model's installation sheet rather than a remembered rule of thumb.
Door swing is its own constraint. GE's measuring guide notes that without roughly 2 inches of space on the hinge side, "the refrigerator will need to be pulled out about 2-inches" for the door to open fully (GE Appliances, measuring for the perfect fit) — which changes the finished depth of the whole run. This is the same class of number covered in installation clearance dimensions, and it belongs on the drawing, not in an email.
What changes when the same cabinet ships to the EU instead of the US?
The module changes, and the two modules are close enough to look interchangeable and far enough apart to fail.
A US 24-inch opening is 609.6 mm, because an inch is exactly 25.4 mm (NIST, unit conversion). The European standard niche is 60 cm — 600 mm. The gap is 9.6 mm: invisible on a rendering, decisive at the site. Bosch states the European convention directly on its own kitchen-planning site: a 60 cm niche takes a standard dishwasher, a 45 cm niche takes a slim one (All-in+ by Bosch, built-in dishwasher dimensions).
So a cabinet run built to a clean 600 mm module and shipped to a US buyer who orders a 24-inch dishwasher is, on paper, 9.6 mm short. Sometimes the tolerance absorbs it. Sometimes the installer trims a stile on site and bills the importer. Either way, nobody finds out until the container is unpacked — unless the opening was stated in both units on the catalog page in the first place.
What should the catalog page actually carry?
Six fields. Every one of them is something a buyer would otherwise email you to ask.
| Field | Example of a usable entry |
|---|---|
| Opening width × height × depth | Stated in mm and inches, measured between inside faces |
| Measurement basis | "Between inside faces of side panels, excluding door and trim" |
| Tolerance | The build tolerance you actually hold, stated as a range, not implied |
| Appliance module it is built for | "Built for a 600 mm European niche" or "built for a US 24 in opening" |
| Required clearances | Rear air gap, top gap, hinge-side allowance for the door |
| Who confirms | "Confirm against the appliance manufacturer's installation template before ordering" |
Here is the practical part. Those six fields are unreadable as a paragraph and unmissable as labels on the drawing itself — the opening dimension drawn on the opening, the clearance drawn behind the cabinet. What makes that work is that the numbers on the image are measured, snapped to the real edges of the object, then exported at the size your catalog or marketplace expects. That is a different job from image generation: an AI image tool will happily render a clean-looking "600 mm" onto a picture, but it never measured anything, and a plausible number in the wrong place is worse than no number at all. Suppliers who have made this switch on cabinet listings see the same effect documented in this wall cabinet size-label case study — the pre-sale questions stop, because the answer is already in the picture.
If you are still setting the base numbers for your range, start from standard cabinet dimensions and then add the appliance openings on top.
Pre-shipment checklist
- Every appliance-adjacent unit lists the opening, not just the cabinet's outside size
- Openings are stated in mm and inches, on the same line
- The measurement basis is written out ("between inside faces, excluding trim")
- Your build tolerance for the opening is published, not assumed
- The target module is named — 600 mm European niche or a US inch opening
- Rear, top and hinge-side clearances appear on the drawing
- The catalog tells the buyer to check the appliance's own installation template
- The same numbers appear on the drawing, the spec sheet and the quotation — no third version in an email
FAQ
What are the standard appliance cutout dimensions?
There is no single standard set. EN 1116:2018 and ISO 3055:2021 define coordinating sizes for kitchen furniture and appliances, but their numeric tables are paywalled and they do not replace a model's installation instructions. In practice Europe clusters around a 60 cm module and North America around inch-based openings, and a cabinetmakers' trade knowledge base states the working reality directly: "There is no standard. American companies tend to be similar, but European companies are different."
Is a 24-inch dishwasher the same as a 60 cm dishwasher?
Not exactly. A 24-inch opening is 609.6 mm and a 60 cm niche is 600 mm — a 9.6 mm difference. The two are close enough that catalogs treat them as equivalent and far enough apart that a tight installation fails. State which module your cabinet was built for.
What is the difference between cutout dimensions and overall dimensions?
Cutout is the empty opening the appliance needs; overall is the appliance's own outside size. GE notes that the cut-out plus the overlap exceeds the overall dimensions, which is why quoting only the overall size tells an installer nothing about whether it will fit.
Does KCMA certification cover appliance openings?
No. ANSI/KCMA A161.1 is a performance and construction standard — shelf loading, drawer cycling, door operation and finish durability. It verifies that the cabinet is built well, not that a particular appliance will fit inside it.
How much clearance should I leave behind a built-in refrigerator?
Follow the specific model's installation sheet. As a reference point, GE publishes 1/8 inch to 1 inch at the sides and 1 inch above the case, with its two support pages giving either "1″ to 2″" or a flat 2 inches at the back — a spread that is itself the argument for citing the model document rather than a general rule.
